Stainless Steel Plate

Name	Detail
Product:	Stainless Steel Sheet, 304 Stainless Steel Plate, 316 Stainless Steel Plate
Application:	In Chemical Industry, Coal, Oil Field Open Machine, Building Materials Heat-resistant Parts
Size:	3/16'' Thick ~ 6'' Thick, Up to 120'' Wide



Pipe Standard:	ASTM A167, ASTM A176, ASTM A240, ASTM A693, ASTM A480




Steel Grades:	300 Series Stainless, 400 Series Stainless
Surface:	Sweet Service, Sour Service, Anti-H2S, NACE MR0175/ISO15156
Zinc Coating:	10~50 g/m2
Packing:	Waterproof Paper Wrapped, Packed in Wooden Cabins
Brand	-

Items	Stainless Steel Plate
Standard	GB/T14976-2002, GB13296-91, GB9948-88, ASTM/ASME A213/SA213, ASTM/ASME A312/SA312, ASTM/ASME A269/SA269, DIN 17458-85, DIN 17456-85, JIS G 3459, JIS G 3463, JIS G 3448, JIS G 344
Size	Sheet (0.2mm–4mm) Slab (4mm–20mm) Thick plate (20mm–60mm) Special thick plate (60–115mm)
Industrial process	hot rolled, hot expanded, cold drawn, and hot galvanized
Tolerance	a) Outer Diameter: 6–32mm ±0.2mm, 32–38 ±0.15mm, 42–60 ±0.20mm, 60mm ±0.25mm b) Thickness: ±10% c) Length: ±5mm
Surface	180G, 240G, 320G Satin / Hairline 400G, 600G Mirror finish
Application	steel bridge, boiler plate, shipbuilding steel, steel armor, automotive steel, roof plate, structural steel, electrical steel etc.
Test	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Chemical Composition of Material	Material	201	202	304	316L	430
	C	≤0.15	≤0.15	≤0.08	≤0.035	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5–7.5	7.5–10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	13–15	14–17	18–20	16–18	16–18
	Ni	0.7–1.1	3.5–4.5	8–10.5	2.0–3.0	–
Mechanical Property	Material Item	201	202	304	316
	Tensile Strength	≥535	≥520	≥520	≥520
	Yield Strength	≥245	≥205	≥205	≥205
	Extension	≥30%	≥30%	≥35%	≥35%
	Hardness (HV)	≤105	≤100	≤90	≤90

For pricing, technical specifications, and availability of this product, please contact our sales team via email below. sales@pipvalcon.co.id
